1. The Schluter KERDI LINE G3 Linear Drain is available in lengths from 500mm to 1200mm, in 100mm increments. Apply Schluter SET, Schluter ALL-SET, Schluter FAST-SET, or unmodified thin-set mortar to the membrane surrounding KERDILINE with a 1/4" x 3/16" (6 x 5 mm) V-notched trowel or the KERDI-TROWEL, which features a 1/8" x 1/8" (3 x 3 mm) square-notched design. KERDI-LINE includes a corresponding polystyrene foam channel support to set the drain elevation to the corresponding KERDI-SHOWER-LT/-LTS shower trays. Adaptor kits are suitable for both mortar beds and KERDI-SHOWER-T/-TS/-TT shower tray applications. Slope the mortar bed using the bonding flange and mortar screeds as guides. The grates are installed in conjunction with a height adjustment collar or lateral adjustment ring, which are made of ABS to allow for simple and convenient adjustment when setting the tile. It ensures a simple and secure connection to the bonded waterproofing assembly, both in the floor area and on adjacent walls. Design and functionality in a unique pairing: Schlter-ARCLINE is a profile system that matches the high-quality bathroom accessories of KEUCO. Availability: Ships from Factory (More Info), Shipping: $49.95 Flat rate ground shipping for unlimited Schluter products in this order. (More Info). KERDI-LINE and the Schluter-Shower System offer an integrated moisture management solution that eliminates leaks and mold growth, and ensures the lasting beauty of your tiled shower. No access to plumbing from below When there is no access to the plumbing from below, the channel body must be set and connected to the waste line simultaneously. The offset outlet is located 8" (20.3 cm) from the edge of the channel body and provides flexibility when obstacles (e.g., floor joists) are encountered during installation. As the name implies, Schlter-KERDI-LINE-VARIO WAVE is a W shaped drainage profile for use with the Schlter-KERDI-LINE-VARIO-H drain. New Road 332 0 obj
<>stream
The integrated bonding flange slides into the adaptor ring, with the over-molded rubber gasket ensuring a watertight seal.KERDI-DRAIN ADAPTOR KITS, available in 5 1/4" (133 mm) and 7 1/2" (191 mm) diameter sizes, are used to convert traditional clamping ring drains to integrated bonding flange drains when removal of the clamping ring drain is not practical (e.g. When cut to 1000mm long this tray works perfectly with a 18mm timber floor and a Schluter DITRA HEAT DUO Installation. KERDI-LINE requires no special maintenance and is resistant to mold and fungi. Refer to local plumbing and/or building codes for any specific requirements in your area. Apply Schluter SET, Schluter ALL-SET, Schluter FAST-SET, or unmodified thin-set mortar to the top of the channel support with a notched trowel and press the channel support firmly onto the underside of the channel body. Slide the adaptor flange into the adaptor ring and ensure full support under the adaptor flange with mortar or the detachable center section of the foam tray. %PDF-1.5
%
The perimeter of the channel body consists of a bonding flange laminated with a collar made of KERDI. The grate assembly can be adjusted to a wide range of tile thicknesses, while the covering support is placed flush with the channel body and can therefore accommodate any thickness covering. Note: Protect the visible surfaces of the grate frame and grate from contact with setting and grouting materials. height-adjustable, individual sizing option (22 - 120 cm), Brushed stainless steel / TRENDLINE powder coated aluminium, simple seal check with opening in protective lid, multi-function protective lid: provides protection and serves as a screed levelling aid, (customisable) spacer, centre marking (bidirectional) and water inspection nozzle. For installation of a shower tray, depending on the installed drain elevation, it may be necessary to install a polystyrene foam panel, backerboard, etc. An intermediate opening 14 mm wide and 140 mm long allows water to flow into the drain. Install the tray as per the instructions in the Schluter-Shower System Installation Handbook. The KERDI-LINE grate assembly consists of a stainless steel frame that can be seamlessly adjusted to the thickness of the ceramic tile or stone covering 1/8" to 1" (3 mm to 25 mm) for standard grate assemblies and 1/4" to 23/32" (6 mm to 18 mm) for style grate assemblies and stainless steel grates that are placed within the frame. The Schluter KERDI LINE G3 Linear Drain is designed to be used with the Schluter pre-formed sloped linear shower trays Schluter KERDI SHOWER LT/LTS Shower Trays.
As such, it eliminates the time and labor involved in building a sloped mortar bed. It is installed directly against the wall, so that the channel body support is in contact with the wall. Each standard assembly is available in a brushed or chrome finish. Unit 1, Barley Close Farm How to Install Schluter-KERDI-LINE linear drain, Schluter-Systems-No Access Plumbing Demonstration with KERDI-LINE, Schluter-KERDI-LINE Grate Assembly & SHOWERPROFILE-S/-R System Profiles, Schluter-KERDI-LINE Tileable Covering Support, How to perform a Water Test with the Schluter-Shower System.
You can also adjust the profile installation height to the thickness of the floor covering by using tile adhesive. Find some existing tutorials and project documentation videos to learn how-to get the best out of our products - for more fun in your life, start now! The channel body features a standard 2" (50 mm) no-hub outlet and is attached to the pipe using an appropriate mechanical no-hub coupling. KERDI-LINE can be installed adjacent to walls or at intermediate locations in showers, wet rooms, and other applications that require waterproofing and drainage. The grates may be removed to clean the drain housing and the drain pipes. Once the tile covering is set and grouted, remove the spacers from the grate frame and insert the grate. The elevation should be set such that the frame will be flush with the surface of the tile covering. Only logged in customers who have purchased this product may leave a review. Bolts are to be finger-tight plus 1/4 turn; do not overtighten, as this may warp the adaptor ring and result in leaks.3. Get early access to deals and special offers. The KERDI-SHOWER-LT/-LTS shower trays are made of lightweight, expanded polystyrene, and feature integrated waterproofing with the KERDI membrane applied on the surface, and a perfect slope so water is funneled directly to the drainage.
It is available with central, offset left, offset right or dual outlets equipped with an odour trap integrated into the drain body and is suitable for perimeter or intermediate installation. Surface Cleaning & Application Ancillaries, Schlter Shower Trays, Drains & Accessories. KERDI-LINE includes a corresponding polystyrene foam channel support and can be installed in conjunction with the matching KERDI-SHOWER-L/-LS sloped trays with integrated KERDI waterproofing or a sloped mortar bed covered with theKERDI waterproofing membrane. Installation instructions for the use of KERDI-DRAIN-A in shower applications can be found in the Schluter-Shower System Installation Handbook. The membrane is adhered to the large integrated bonding flange to form a waterproof connection at the top of the drain assembly. For installation adjacent to the wall, the channel body must be aligned in accordance with the thickness of the wall covering.
The SQUARE (B) option is also available with a locking mechanism (brushed stainless steel, 3/4" 19 mm frame only) for applications where tamper resistance is desired or required (e.g., healthcare and education facilities, etc.). Clean the grates using common household cleaning agents. Schlter-KERDI-LINE-VARIO COVE is a 120 cm cove-shaped drainage profile, which can be individually cut to size, for use with the Schlter-KERDI-LINE-VARIO-H drain. Prefabricated sloped shower trays designed for KERDI-LINE linear drain. KERDI-LINE can be installed in conjunction with the provided channel support as described below or set in loose mortar. The KERDI-LINE channel body is made of formed stainless steel and features a bonding flange laminated with a collar made of KERDI waterproofing membrane. This connection is made watertight via the rubber gasket and Schluter-KERDI-FIX adhesive/sealant. Do not use abrasive or alkaline cleaning agents. 1. 5.
Many classic designs owe their success to the concept of "Less is more". Embed KERDI in the bond coat with the flat side of the trowel to ensure full coverage and remove air pockets b. DITRA: Apply Schluter SET, Schluter ALL-SET, Schluter FAST-SET, or unmodified thin-set mortar to the mortar bed surrounding KERDI-LINE with a 1/4" x 3/16" (6 x 5 mm) V-notched trowel or the DITRA-TROWEL, which features an 11/64" x 11/64" (4.5 x 4.5 mm) square-notched design.
KERDI-BOARD is a lightweight XPS foam panel that is inherently waterproof. Insert the foam spacers in the grate frame to reinforce it during the remainder of the installation. Continuing Education for Architects & Designers. Apply Schluter SET, Schluter ALL-SET, Schluter FAST-SET, or unmodified thin-set mortar to the substrate where the drain is to be placed with a notched trowel. Align the bolt pattern of the clamping ring with the matching punch-outs in the adaptor ring. Check to make sure the KERDI-LINE is level.
For the best experience on our site, be sure to turn on Javascript in your browser. Please note: Grate assemblies included with the plastic KERDI-DRAIN featuring 3" (75 mm) outlets and the residential adaptor kits only allow vertical and tilt adjustment (no lateral adjustment). Connection to waterproofing membranes The KERDI or DITRA waterproofing membranes can be installed as soon as the mortar bed can be walked upon. When the Schluter KERDI LINE G3 Linear Drain is used in conjunction with the waterproofing systems Schluter KERDI 200 Membrane, Schluter DITRA 25 Matting, Schluter DITRA HEAT Matting or Schluter KERDI BOARD and the associated system sealing adhesives Schluter KERDI COLL L or Schluter KERDI FIX, this results in certified bonded waterproofing assemblies with a connected linear drainage. %%EOF
You can download our Excel configurator tool here: Linear drainage with a slim and unobtrusive cove-shaped profile, Linear drainage with a slim and unobtrusive W shaped profile, The design drainage profile can be cut to size with millimetre precision, Drainage profiles in two elegant design options. The opening of this profile is elegantly concealed by a removable cover panel. The SOLID and SQUARE designs are available in brushed stainless steel or chrome finish with matching frame. Schlter-Systems is well known for its slim drainage solutions this system is the intelligent next generation of our proven technology. This series of shower drain grates features designs that fit into a virtually invisible frame, resulting in a stylish and truly seamless look for shower floors. Schlter-QUADEC is a decorative profile made of coloured PVC for creating symmetrically angled external corners in tile coverings and finished edges of tiled skirtings and coverings. Regular cleaning maintains the neat appearance of stainless steel and reduces the risk of corrosion. Tiling supplies direct 2022 All Rights Reserved. This product is already in quote request list. KERDI-LINE consists of a formed stainless steel channel body and grate assembly or covering support to which tile is applied. The floor can be sloped on a single plane to KERDI-LINE, which enables the use of largeformat tiles and creates interesting design opportunities. Schluter-KERDI-LINE is a low profile linear floor drain specifically designed for bonded waterproofing assemblies. Prefabricated sloped shower trays designed for KERDI-LINE linear drain, Bonded waterproofing and vapor-retardant membrane, Waterproof, multifunctional tile substrate and building panel, Cover plate used to connect multiple KERDI-LINE drains, Two-part profile with tapered edge to cover adjoining tile edges, Transition profile covers exposed wall where floor slopes to linear drain, Profile that forms a splashguard in curbless showers, Contact us: 888-472-4588
The award went to the combination of the KERDI-LINE-VARIO-H drain with the WAVE drainage profile. Re-insert and tighten the bolts using a star pattern. The wave shaped drain can be rotated by 360 by loosening the clamping ring, which makes the linear drainage adaptable to any connection configuration in the existing building. Product Datasheet Installation Instructions. KERDI-LINE is an elegant, low profile linear floor drain specifically designed for bonded waterproofing assemblies. With point drains, shower bases must be sloped from all directions to the drain, therefore limiting tile selection to mosaics or other relatively small-format tiles. With KERDI-LINE, the shower base can be sloped on a single plane, enabling the use of attractive large format tiles. Easy to use out of box with kerdi rough in.
KERDI-LINE has achieved a new dimension of flexibility: Floor-level showers with KERDI-LINE-VARIO, Schlter-KERDI-LINE-VARIO | Installation instructions [pdf - ], Schlter-KERDI-LINE-VARIO | The profile of linear drainage [pdf - 0,9 MB], https://www.schlueter-systems.com/dhert2/, Schlter-KERDI-LINE-VARIO linear drainage in a versatile new concept, Schlter-Systems: Schweiz Suisse Svizzera, Palettenkonfigurator fr Schlter-KERDI-BOARD, Schlter-KERDI-BOARD: Innovative Installation Systems for Tile and Stone, Schlter-BEKOTEC-THERM: Underfloor Heating System, Schlter-LIPROTEC: Light in a new dimension, https://www.schlueter-systems.com/bekotec-therm-ear.aspx, https://www.schlueter-systems.com/bekotec-therm-ear-wl.aspx, https://www.schlueter-systems.com/bekotec-therm-eet.aspx, https://www.schlueter-systems.com/bekotec-therm-ebc.aspx, https://www.schlueter-systems.com/bekotec-therm-er.aspx, https://www.schlueter-systems.com/bekotec-therm-er-wl.aspx, DITRA-HEAT-E Controller Installation Videos, AGB DK: Leverings- og betalingsbetingelser, AGB EN_INT: Delivery and Payment Conditions, AGB FR_BE / FR_CH: Conditions de livraison et de paiement, AGB FR_FR: CONDITIONS GNRALES DE VENTE SCHLTER-SYSTEMS, AGB IT_CH: Condizioni di fornitura e pagamento, AGB IT_IT: Condizioni generali di vendita, AGB BE_NL: Leverings- en betalingsvoorwaarden, AGB PT: Condies de Fornecimento e Pagamento, AGB HU: Szlltsi s fizetsi felttelek, AGB DE: Lieferungs- und Zahlungsbedingungen, The drainage profiles can be individually, The profiles in the design options COVE and WAVE. Link to cart successfully copied to clipboard. The trays are available for wall (-LS) or center (-L) drain placement. The universal linear drainage system KERDI-LINE-VARIO can be installed in an intermediate position or against a wall. Drain grates are available in stainless steel with a polished or oil-rubbed bronze finish and in anodized aluminum with a brushed copper, brushed brass, or brushed nickel finish. 227 0 obj
<>
